MIL-HJ-450
Heating jacket up to 450°C
Our hand-made heating jackets are customizable and can be produced for a wide range of geometric shapes
- Slitted heating jackets for easier handling
- No additional thermal insulation necessary
- Wide variety of geometric shapes possible
- Cutouts can be considered
- Permanently integrated temperature sensor
Technical data
| Nominal voltage | Up to 500 V AC |
| Rated power | Process-dependent |
| Outer jacket | Aluminium coating |
| Inner jacket | Glass fiber |
| Isolation | Glass needle felt, thickness depending on installation conditions |
| Heatsealing band | Glass fiber braided resistance element |
| Mounting type | Hooks and loop tape, eyelets or Velcro |
| Protection class | I |
| Protection type | IP 20 |
| Temperature sensor (permanently installed) | Pt100 or thermocouple – according to customer specification |
| Max. heatsealing band temperature | 450°C |
| Mains connection cable | customized |
